non-invasive high intensity focused ultrasound tumor therapy system
principle of hifu-2001hifu-2001 is a non-invasive carcinoma treatment system. the system is controlled by a powerful pc with dedicated software, which automatically transmits hifu beams to the precisely defined treatment area. the system can automatically calculate and design the size and shape of treatment area. due to significant energy deposition at the focus, temperature within the tissue rises up between 65℃ and 100℃, destroying the diseased tissue by coagulation necrosis. nowadays, there is no optimal single method for cancer treatment. comprehensive therapy programs that utilize multiple paralleled methods are adopted to treat different cancer cases. hifu-2001 provides a high-tech method for cancer treatment with accurate therapeutic effects and high safety.
- description
- feature:non-invasive and radiation freeno bleeding and pain free during / after treatmentfocused on targeted treatment areareal time visualization during scanning /firing phasescomputer-controlled automated treatmentsimple monitoring by user-friendly interfacecompatible with other treatment modalitiesrepeat treatment and salvage treatment allowedoutpatient procedure
clinical indicationsliver cancer, pancreatic cancer, tumor thrombi in portal veinprostate cancer, bladder cancer, womb cancerrectal cancer, renal cancer, soft tissue sarcomabreast cancer, other malignant tumors in abdomenbph, other benign tumors
unique techniqueadvanced double focusing (adf)with the unique adf technique, the ultrasound beam is dispersed onto 8 individual sub-ejectors. the eight sub-ejectors with diameter of 60mm further focus the beam to a single point. the adf technique can achieve non-painful treatment purpose.thermal coagulationhifu-2001 can increase the temperature of tumor tissue up to 65℃-100℃. when the temperature comes to 65℃, the tumor cells can be destroyed in 0.3 seconds. at the temperature of 100℃, the tumor cells can be killed within 0.1 second.
 |
|
 |
